ARP is a manufacturer of fasteners/bolts found in engines and drivelines, ranging from OEM replacement parts to specialty hardware for racing applications. ARP is the world leader in fastener technology.
ARP sind ein Hersteller von Verbindungselementen (Bolzen und Stehbolzen) im Motoren und Antriebsstränge, die von OEM-Ersatzteile zu Spezialhardware für den Rennsport gefunden.
ARP ist weltweit führend in der Befestigungstechnik.
Springs data:
Seat pressure - 77lbs @ 40.10mm
Open (lift) pressure - 180lbs @ 10mm
Spring coil bind - 27.00mm
Rate - 10.30lbs/mm
Max lift - 12.20mm
Outer spring outer diameter: 26.50mm
Outer spring inner diameter: 18.70mm
Inner spring outer diameter: 21.60mm
Inner spring inner diameter: 13.80mm
Set includes:
Dual springs: 24 pcs. SPR-FE20BE
Titanium retainers: 12 pcs. RET-BMB48/TE and 12 pcs. RET-BMB48/TI
ARP is a manufacturer of fasteners/bolts found in engines and drivelines, ranging from OEM replacement parts to specialty hardware for racing applications. ARP is the world leader in fastener technology.
|
Product detailed specification |
|
|
Model number |
TIVN-1058/MCIVN-1400S |
|
Head diameter |
30.10mm |
|
Stem diameter |
4.96mm |
|
Length |
99.50mm |
|
Material |
Black nitrided stainless steel |
|
Fits for |
BMW / Toyota - Supercharged B38 / B48 / B58 |
Athena Racing 330-Serie Cooper Ring Zylinderkopfdichtung.
Für spezifische Hochpferdestärken Motorleistungen erheblich durch den Einsatz Athena Cooper Ring Dichtungen verbessert werden, die mit INOX Stahlring geliefert werden. Diese Technologie bietet gegenüber herkömmlichen Feuerring Lösungen.
Cooper Rings sind Übermaß (auch fit für übergroße Bohrungen).
|
Teilenummer beginnt 330 |
|
|
Athena Vorteile |
|
|
Verstärktes Material |
OE genehmigt Asbestfreie Verbund Rohstof |
|
Edelstahlringen (AISI304) |
Einzelne Edelstahlringe gewährleisten maximale Besiegelung um die Zylinderbohrungen, unter extremen Bedingungen, auch mit dem NOS-System und/oder Turbo-Aufladung, wenn die MLS Dichtung unfähig abgedichtet Brennkammer arbeitet. Zylinderkopf und Motorblock benötigt keine speziellen Behandlungen. |
|
Silikon Beading |
Silikon Beading wird auf kritische Bereiche angewendet zu verbessern Abdichten um alle Kühlwasser- und Ölkanäle. |
|
Product detailed specification |
|
|
Bore size |
82.00mm |
|
Stroke |
94.60mm |
|
JE Pistons compression ratio (CR) |
10.5:1 |
|
OEM compression ratio (CR) |
11.0:1 |
|
Dome volume (CC) |
-11.10cm3 |
|
Compression height (CH) |
33.25mm |
|
Pin diameter |
22mm |
|
Features |
Accepts Turbo and Nitrous |
|
Fits for |
Toyota / BMW - 3.0 Turbo (B58B30) |
|
Product detailed specification |
|
|
Bore size |
83.00mm |
|
Stroke |
94.60mm |
|
JE Pistons compression ratio (CR) |
10.5:1 |
|
OEM compression ratio (CR) |
11.0:1 |
|
Dome volume (CC) |
-11.10cm3 |
|
Compression height (CH) |
33.25mm |
|
Pin diameter |
22mm |
|
Features |
Accepts Turbo and Nitrous |
|
Fits for |
Toyota / BMW - 3.0 Turbo (B58B30) |
|
Product detailed specification |
|
|
Bore size |
82.00mm |
|
Stroke |
94.60mm |
|
Mahle compression ratio (CR) |
10.5:1 |
|
OEM compression ratio (CR) |
11.0:1 |
|
Dome volume (CC) |
-4cm3 |
|
Compression height (CH) |
33.27mm |
|
Pin diameter |
22mm |
|
Features |
Accepts Turbo and Nitrous |
|
Fits for |
Toyota / BMW - 3.0 Turbo (B58B30) |
|
Part number starting with 330 |
|
|
Athena advantages |
|
|
Reinforced material |
Asbestos free composite raw material OE approved |
|
Stainless steel ring (AISI304) |
Separate stainless steel rings assure maximum sealing around cylinder bore also on NOS and/or turbo charged engine where boost is over 2 bars. No head and block machining required |
|
Silicon beading |
Silicon-based beading is applied on critical areas to improve sealing around all cooling water and oil passages |
