Product detailed specification |
|
|
Bore size |
81.50mm |
|
Stroke |
87.20mm |
|
MAHLE compression ratio (CR) |
12.4:1 |
|
OEM compression ratio (CR) |
10.0:1 |
|
Dome volume (CC) |
9.1cm3 |
|
Compression height (CH) |
30.00mm |
|
Pin diameter |
21mm |
|
Features |
4032 alloy |
|
Fits for |
Honda - 1.8 16V (B18C1) |
| ENGINE BEARINGS | ||
 |
CON ROD BEARING SET |
|
| Part# | ||
| 4B1925H |
4B1925HX |
|
| Sizes | STD, 025, .25 | STD |
| Oil Clearance | Standard | + 0.001" Extra |
| Half Type | Identical Halves | |
| Material |
Tri-metal Hardened steel backs |
|
| Min Std Shaft Size |
1.7707in / 44.976mm |
|
| Max Std Shaft Size |
1.7717in / 45mm |
|
| Min Std Tunnel Size |
1.8898in / 48mm |
|
| Max Std Tunnel Size |
1.8898in / 48mm |
|
| Max Wall at Crown |
0.0591in / 1.502mm |
0.0586in /1.489mm |
| Max Overall Length |
0.6890in / 17.5mm |
|
| Notes | ||
|
Diagram |
 |
|
|
|||||||
| Quantity | 4 | ||||||
| Crankshaft | 45.001 / 44.976 | ||||||
| Housing | 48.001 / 48.024 | ||||||
| Max Wall | 1.501 | ||||||
| Max Length | 17.501 |
