| ENGINE BEARINGS | ||
 |
CON ROD BEARING SET |
|
| Part# | ||
| 4B1606H |
4B1606HX |
|
| Sizes | STD, .025, .25, .50 | STD |
| Oil Clearance | Standard | + 0.001" Extra |
| Half Type | Identical Halves | |
| Material |
Tri-metal Hardened steel backs |
|
| Min Std Shaft Size |
1.8802" /47.758mm |
|
| Max Std Shaft Size |
1.8810" /47.778mm |
|
| Min Std Tunnel Size |
1.9921" /50.600mm |
|
| Max Std Tunnel Size |
1.9929" /50.619mm |
|
| Max Wall at Crown |
0.0553" / 1.405mm |
0.0548" /1.392mm |
| Max Overall Length |
0.748" / 19.00mm |
|
| Notes | Bearing has 1.65mm oil hole at crown | |
|
Diagram |
 |
|
Engines Audi 2.2 2.3 20V (incl. Turbo) S2, RS2, 200, S4, S6. 3B, 7A, AAN, ADU, ABY
| ENGINE BEARINGS | ||
|
CON ROD BEARING SET |
|
| Part# | ||
| 4B1606H |
4B1606HX |
|
| Sizes | STD, .025, .25, .50 | STD |
| Oil Clearance | Standard | + 0.001" Extra |
| Half Type | Identical Halves | |
| Material |
Tri-metal Hardened steel backs |
|
| Min Std Shaft Size |
1.8802" /47.758mm |
|
| Max Std Shaft Size |
1.8810" /47.778mm |
|
| Min Std Tunnel Size |
1.9921" /50.600mm |
|
| Max Std Tunnel Size |
1.9929" /50.619mm |
|
| Max Wall at Crown |
0.0553" / 1.405mm |
0.0548" /1.392mm |
| Max Overall Length |
0.748" / 19.00mm |
|
| Notes | Bearing has 1.65mm oil hole at crown | |
|
Diagram |
|
|
Engines Audi 2.2 2.3 20V (incl. Turbo) S2, RS2, 200, S4, S6. 3B, 7A, AAN, ADU, ABY
| ENGINE BEARINGS | ||
|
CON ROD BEARING SET |
|
| Part# | ||
| 4B1606H |
4B1606HX |
|
| Sizes | STD, .025, .25, .50 | STD |
| Oil Clearance | Standard | + 0.001" Extra |
| Half Type | Identical Halves | |
| Material |
Tri-metal Hardened steel backs |
|
| Min Std Shaft Size |
1.8802" /47.758mm |
|
| Max Std Shaft Size |
1.8810" /47.778mm |
|
| Min Std Tunnel Size |
1.9921" /50.600mm |
|
| Max Std Tunnel Size |
1.9929" /50.619mm |
|
| Max Wall at Crown |
0.0553" / 1.405mm |
0.0548" /1.392mm |
| Max Overall Length |
0.748" / 19.00mm |
|
| Notes | Bearing has 1.65mm oil hole at crown | |
|
Diagram |
|
|
Engines Audi 2.2 2.3 20V (incl. Turbo) S2, RS2, 200, S4, S6. 3B, 7A, AAN, ADU, ABY.
| ENGINE BEARINGS | ||
|
CON ROD BEARING SET |
|
| Part# | ||
| 4B1606H |
4B1606HX |
|
| Sizes | STD, .025, .25, .50 | STD |
| Oil Clearance | Standard | + 0.001" Extra |
| Half Type | Identical Halves | |
| Material |
Tri-metal Hardened steel backs |
|
| Min Std Shaft Size |
1.8802" /47.758mm |
|
| Max Std Shaft Size |
1.8810" /47.778mm |
|
| Min Std Tunnel Size |
1.9921" /50.600mm |
|
| Max Std Tunnel Size |
1.9929" /50.619mm |
|
| Max Wall at Crown |
0.0553" / 1.405mm |
0.0548" /1.392mm |
| Max Overall Length |
0.748" / 19.00mm |
|
| Notes | Bearing has 1.65mm oil hole at crown | |
|
Diagram |
|
|
Engines Audi 2.2 2.3 20V (incl. Turbo) S2, RS2, 200, S4, S6. 3B, 7A, AAN, ADU, ABY.
Stahlzahnrad Info:
• Dieses verstärkte Kurbelwellenrad wurde speziell für leistungsgesteigerte Turbomotoren hergestellt, bei denen das originale Kurbelwellenrad den Belastungen nicht standhält
• OEM Teilenummer: 034105263A
• Material: 42CrMo4
Satz enthält:
1 Kurbelgehäusedichtung
1 Kurbelwellendichtung Rückseite
1 Kurbelwellendichtung Vorderseite
1 Ölpumpe Dichtung
und andere.
Nockenwellenrad Info:
• Hochwertiges Tommis Billet Aluminium verstellbare Nockenwellenrad für Audi 2.2 Turbo Motor.
• Enthält Nockenposition Scheibenblende für diesen Motor erforderlich.
• Arbeitet mit der Original Hall Sensor.
• Breite 21mm.
• Schwarz eloxiert.
Länge: 1208mm
Breite: 19mm
Anzahl der Zähne: 151
Gates Zahnriemen bieten eine präzise Passform mit einfacher Montage und keine Interferenzmotivschaden - genau das, was Sie vom Weltmarktführer in Zahnriemen erwarten können.
- Zugschnur verstärkt mit hochwertigen, hochfesten Glasschnüren.
- Greifen von Zähnen mit Aramidfasertechnologie und hochsättigenden HNBR-Elastomerkompositen für außergewöhnliche Haltbarkeit und Hitzebeständigkeit.
- Verschleißfeste Zahnjacke unterstützt mit verstärktem Nylongewebe und Doppelzahnstabilität.
Die überlegene Konstruktion von Gates-Zahnriemen macht sie zu 300 Prozent stärker als der Standard-Aftermarket-Zahnriemen.
8740 Chrome Moly: Until the development of today’s modern alloys, chrome moly was popularly considered a high strength material. Now viewed as only moderate strength, 8740 chrome moly is seen as a good tough steel, with adequate fatigue properties for most racing applications, but only if the threads are rolled after heat-treatment, as is the standard ARP production practice. Typically, chrome moly is classified as a quench and temper steel, that can be heat-treated to deliver tensile strengths between 180,000 and 210,000 psi
