| Pairs & PN |
|
||||||
|---|---|---|---|---|---|---|---|
| Quantity | 4 | ||||||
| Crankshaft | 46.007 / 45.992 | ||||||
| Housing | 48.999 / 49.019 | ||||||
| Max Wall | 1.488 | ||||||
| Max Length | 17.351 |
Detali informacija
Gamintojas: FCP Engineering
Modelis: FCPRHMI138534820
Profilis: H
Ilgis tarp centrų: 138.53mm
Didžiosios skylės diametras: 48mm
Piršto diametras: 20mm
Kiekis: 4 vnt., 8 vnt. ARP2000 5/16" varžtų
Pagaminta iš: kaltinio plieno 4340 EN24er
Rekomenduojama maksimali variklio galia: 600AG (4 cilindrams)
Maksimalūs variklio sūkiai: 9000aps./min.
Citroen, Peugeot, Mini Cooper S (MKII / R56) - 1.6 16V Turbo (N12B16A, N14B16A, N18B16A/B/C)
|
Product detailed specification |
|
|
Bore size |
77.00mm |
|
Stroke |
85.80mm |
|
Wiseco compression ratio (CR) |
10.1:1 |
|
OEM compression ratio (CR) |
11.0:1/10.5:1 |
|
Dome volume (CC) |
+1cm3 |
|
Compression height (CH) |
28.50mm |
|
Pin diameter |
20mm |
|
Features |
Round piston skirt |
|
Fits for |
Mini Cooper S MKII - 1.6 16V (N12B16A, N14B16A) |
Seat pressure - 70lbs @ 33.6mm
Open (lift) pressure - 163lbs @ 10mm
Spring coil bind - 22.20mm
Rate - 9.70lbs/mm
Max lift - 11.40mm
Outer diameter: 23.50mm/16.50mm
Inner diameter: 19.30mm/12.30mm
Set includes:
Beehive springs: 16 pcs. SPR-MC56BE
Titanium retainers: 16 pcs. RET-MC56/T1
