| Oil Clearance | Standard |
| Half Type | Identical Halves |
| Material | Tri-metal Hardened steel backs |
| Min. Std Shaft Size | 2.0465in / 51.981mm |
| Max. Std Shaft Size | 2.0472in / 51.999mm |
| Min. Std Tunnel Size | 2.1654in / 55.001mm |
| Max. Std Tunnel Size | 2.1663in / 55.024mm |
| Max Wall at Crown | 0.0589in / 1.496mm |
| Max Overall Length | 0.7677in / 19.5mm |
| Weight | 0.33 |
| Oil Clearance | Standard |
| Half Type | Identical Halves |
| Material | Tri-metal Hardened steel backs |
| Min. Std Shaft Size | 2.0465in / 51.981mm |
| Max. Std Shaft Size | 2.0472in / 51.999mm |
| Min. Std Tunnel Size | 2.1654in / 55.001mm |
| Max. Std Tunnel Size | 2.1663in / 55.024mm |
| Max Wall at Crown | 0.0589in / 1.496mm |
| Max Overall Length | 0.7677in / 19.5mm |
| Weight | 0.33 |
| Sizes | STD, .025, .25, .50 |
| Oil Clearance | Standard |
| Half Type | Upper & Lower |
| Material | Tri-Metal |
| Min. Std Shaft Size | 2.6373in / 66.987mm |
| Max. Std Shaft Size | 2.6378in / 67.000mm |
| Min. Std Tunnel Size | 2.8346in / 71.999mm |
| Max. Std Tunnel Size | 2.8352in / 72.014mm |
| Max Wall at Crown | 0.0981in / 2.491mm |
| Max Overall Length | 0.8858in / 22.5mm (8088H/HX) 0.7677in / 19.5mm (8089H/HX) |
| Weight | 0.45 |
| Notes | This part has no notch. |
| Oil Clearance | Standard |
| Half Type | Identical Halves |
| Material | Tri-metal Hardened steel backs |
| Min. Std Shaft Size | 2.0465in / 51.981mm |
| Max. Std Shaft Size | 2.0472in / 51.999mm |
| Min. Std Tunnel Size | 2.1654in / 55.001mm |
| Max. Std Tunnel Size | 2.1663in / 55.024mm |
| Max Wall at Crown | 0.0589in / 1.496mm |
| Max Overall Length | 0.7677in / 19.5mm |
| Weight | 0.33 |
|
Product detailed specification |
|
|
Model number |
TIVN-1093D |
|
Head diameter |
36.00mm |
|
Stem diameter |
5.48mm |
|
Length |
95.05mm |
|
Material |
Black nitrided stainless steel |
|
Fits for |
Toyota - 4.7L V8 (2UZ-FE) |
|
Product detailed specification |
|
|
Model number |
TEVI-1093D |
|
Head diameter |
30.50mm |
|
Stem diameter |
5.47mm |
|
Length |
95.10mm |
|
Material |
Inconel |
|
Fits for |
Toyota - 4.7L V8 (2UZ-FE) |
