VAG 1.4 16V TSI Wiseco pistons CR 10:1 77mm KE192M77AP

Part number KE192M77AP
Wiseco forged piston kit (4 pcs.) 77.00mm CR 10.0:1
Audi / Seat / Skoda / VW - 1.4 16V TSI (CAVD, CAXA, CAVA, BLG)
€829.00
Availibilty:1 items
Information

Product detailed specification

Bore size

77.00mm

Stroke

75.60mm

Wiseco compression ratio (CR)

10.0:1

OEM compression ratio (CR)

10.0:1

Dome volume (CC)

-8.4cm3

Compression height (CH)

29.11mm

Pin diameter

19mm

Features

Accepts Turbo and Nitrous, Round piston skirt
Oil squirter removal or spacers required

Fits for

VAG - 1.4 16V TSI EA211

Armor Plated wiseco pistons have almost a bronze colored tint to the top of the piston and the wrist pin bore. Wiseco's Armor Plating is an abrasion resistant plating that raises the hardness of the aluminum, increases the durability of the ring grooves, prevents micro-welding of the piston rings, reduces carbon buildup and combats corrosion caused by detonation. Wiseco's most popular pistons now include Armor Plating.
