Audi TTRS / RS3 CEPA CEPB ACL Race Series main bearings 6M5563HX-STD

JE's patented Perfect Skirt coating makes piston slap, false knock, and cold-start wear a thing of the past.
For the first time ever, 2618-alloy pistons can be installed with piston-to-wall clearances near that of an OEM piston!

Product detailed specification

Manufacturer: FCP Engineering
Model: FCPRHA14450622-5
Profile: H-beam
C to C: 144mm
Big end diameter: 50.6mm
Pin diameter: 22mm
Quantity: 5 pcs., 10 pcs. ARP2000 3/8" bolts
Made of: forged steel 4340 EN24er
Advertised horsepower rating: 700HP (5 cylinder)
Advertised RPM rating: 9000RPM

Spring data:
Seat pressure - 73lbs @ 38.60mm (intake), 85lbs @ 37.20mm (exhaust)
Open (lift) pressure - 178lbs @ 10mm (intake), 109lbs @ 10mm (exhaust)
Max lift - 12.50mm (intake), 11.00mm (exhaust)
Spring coil bind - 24.90mm
Rate - 10.50lbs/mm
Spring outer diameter - 24.00mm
Spring inner diameter - 16.50mm

Set includes:
Single springs - 20 pcs. SPR-A2416-5
Titanium retainers - 20 pcs. RET-A2416-N2
