| ENGINE BEARINGS | ||
 |
CON ROD BEARING SET |
|
| Part# | ||
| 6B1490H |
6B1490HX |
|
| Sizes | STD, .025, .25, .50 | STD |
| Oil Clearance | Standard | + 0.001" Extra |
| Half Type | Identical Halves | |
| Material |
Tri-metal Hardened steel backs |
|
| Min Std Shaft Size |
1.7707in / 44.975mm |
|
| Max Std Shaft Size |
1.7713in / 44.991mm |
|
| Min Std Tunnel Size |
1.8898in / 48.000mm |
|
| Max Std Tunnel Size |
1.8904in / 48.016mm |
|
| Max Wall at Crown |
0.0588in / 1.493mm |
0.0583in / 1.481mm |
| Max Overall Length |
0.709in / 18.00mm |
|
| Notes | ||
|
Diagram |
 |
|
Athena Racing 330 series Cooper Ring cylinder head gasket.
For specific high horsepower applications, engine performance can be significantly improved by using Athena Cooper Ring gaskets, that are supplied with INOX steel ring. This technology outperforms conventional fire ring solutions.
Cooper Rings are oversize (also fits for oversize bores).
Part number: 330023R
Gasket thickness: 1.50mm
Bore size: 87.60mm
|
Part number starting with 330 |
|
|
Athena advantages |
|
|
Reinforced material |
Asbestos free composite raw material OE approved |
|
Stainless steel ring (AISI304) |
Separate stainless steel rings assure maximum sealing around cylinder bore also on NOS and/or turbo charged engine where boost is over 2 bars. No head and block machining required |
|
Silicon beading |
Silicon-based beading is applied on critical areas to improve sealing around all cooling water and oil passages |
Athena Racing 330 series Cooper Ring cylinder head gasket.
For specific high horsepower applications, engine performance can be significantly improved by using Athena Cooper Ring gaskets, that are supplied with INOX steel ring. This technology outperforms conventional fire ring solutions.
Cooper Rings are oversize (also fits for oversize bores).
|
Part number starting with 330 |
|
|
Athena advantages |
|
|
Reinforced material |
Asbestos free composite raw material OE approved |
|
Stainless steel ring (AISI304) |
Separate stainless steel rings assure maximum sealing around cylinder bore also on NOS and/or turbo charged engine where boost is over 2 bars. No head and block machining required |
|
Silicon beading |
Silicon-based beading is applied on critical areas to improve sealing around all cooling water and oil passages |
Part number 7M5532H-STD
ACL Race Series main bearings
Audi / VW - 2.8 2.9 3.2 3.6 VR6 R32 R36 (BUB, BHK, AES, AUE, ABV, AAA, AMY)
|
|||||||
| Quantity | 6 | ||||||
| Crankshaft | 44.991 / 44.973 | ||||||
| Housing | 48.001 / 48.016 | ||||||
| Max Wall | 1.491 | ||||||
| Max Length | 18.001 |
